Automatic high-speed tapping machine

Quantity 1

Specifications:

Features:

1. This machine is designed to fall freely according to the weight of the material itself, and the datum surface is attached to the plane, so the processing is smoother.

2. This machine is suitable for tapping processing of ultra-thin, polygonal, non-standard and missing materials.

3. Pneumatic automatic feeding and clamping, tapping and unloading, fast operation.

4. The mold change is quick and easy, suitable for the processing of various types of programs, and one machine with multiple functions.

5. The processed material is rotated and tapped, and the material is in a static state after processing, and the material is discharged without being injured.

6. PLC can be programmed to control, detect that there is no material and stop, and the machine will not continue to run under the condition of no material.

7. Lift the cover and stop, no need to change to adjust the speed.

8. Equipped with frequency converter, there is no need to change the pulley to adjust the speed.

9. Equipped with torque detection, which can ensure the quality of the material and prevent poor quality caused by the blunt tooth tapping.

10. It can be connected to a remote monitoring system, up to 40 communication connections can be made at the same time, and the operation status can be controlled at any time.
