180 X 400 LVD HYDRAULIC PRESS BREAK MACHINE

View Seller Detail

MSZ-4061

Price On Request

Condition	GOOD & RUNNING
Location	OUT OF INDIA
Make	LVD
Model	PPBLH 200/30
speed of machine	6.7 mm/sec
Type	HYDRAULIC PRESS BREAK
With tool kit	11.5 TON
Year of Mfg	1992
Max cutting of width	400 mm
Max cutting thickness	180 mm
Quantity	1

Specifications:

MACHINE IS IN RUNNING AND GOOD CONDITION
- Pressure capacity 200 t
- Working width 3050 mm
- Clearance between the columns 2550 mm
- Table width 180 mm
- Throat depth 250 mm
- Installation height 400 mm
- Feed speed 80 mm/sec.
- Working speed 6.7 mm/sec.
- Retraction speed 67 mm/sec.
- Ram stroke 150 mm
- Adjustment range of fixed stops 120 mm
- Drive 400 V 14.5 kW
- Space requirement approx. W 3800 x H 2980 x D 1700 mm
