300 x 420 FARMER BAND SAW MACHINE

View Seller Detail

MSZ-4083

Price On Request

Condition	GOOD & RUNNING
Location	OUT OF INDIA
Make	FARMER
Model	S420
Weight	950 kg
Year of Mfg	1992
Flat Size 1	300 mm
Flat Size 2	420 mm
Max Round Size	360 mm
Table size ( small size ) X	1100
Table size (large size ) Y	2500
Quantity	1

Specifications:

MACHINE IS IN RUNNING AND GOOD CONDITION
- Cutting range at 90 round 420 mm
- flat 635 x 290 mm
- Cutting range 45 round 360 mm
- flat 420 x 300 mm
- Saw blade dimensions 5200 x 32 x 1.1 mm
- Continuously variable cutting speeds 18 to 108 m/min
- Hydraulic raising and lowering of the saw frame
- Hydraulic material clamping device
- Cutting pressure continuously adjustable 0 - 10 m/min
- Total drive power 400 V / 2.2 kW
- Coolant system
- Machine is mounted on a bogie
- Motor-driven infeed roller conveyor 4000 mm
- Outfeed roller conveyor with dimension stop 6000 mm
- Space required approx. W 2500 x H 1400 x D 1100 mm
- Machine weight approx. 950 kg
- Weight of roller conveyors 2000 kg
