270 X 300 JAESPA HYDRAULIC AUTOMATIC BAND SAW MACHINE

View Seller Detail

MSZ-4085

Price On Request

Condition	GOOD & RUNNING
Location	OUT OF INDIA
Make	JAESPA
Model	W 270 A
Type	Hydraulic automatic band saw
Weight	1700 KG
Year of Mfg	1998
Flat Size 1	270 mm
Flat Size 2	300 mm
Max Round Size	320 mm
Table size ( small size ) X	1700
Table size (large size ) Y	2600
Quantity	1

Specifications:

MACHINE IS IN RUNNING AND GOOD CONDITION

- Cutting range at 90 round 320 mm
- flat 300 x 270 mm
- Material feed stroke up to 500 mm
- Unlimited multiple strokes
- Remaining piece length in automatic mode 125 mm
- Saw blade dimensions 3900 x 27 x 0.9 mm
- Cutting speed 17 to 106 m/min
- Hydraulic lifting and lowering of the saw frame
- Upper stroke limit of the saw frame
- Cutting pressure continuously adjustable 0 - 10 m/min
- Hydraulic material vice
- Chip conveyor
- Saw blade cleaning brush
- Coolant system
- Drive 400 V / 2.2 kW
- Space required approx. W 2300 x H 1700 x D 2600 mm
- Weight approx. 1700 kg
- Roller conveyor 2000 mm
